2.1.3.2 Datum transformation

The coordinates of the GPS evaluation are primarily geocentric coordinates on the WGS84 Ellipsoid. For application in the bundle adjustment, the GPS-software transforms these coordinates into the system, where also the control points are defined, e.g. UTM. Due to geoid undulations and/or due to the partly not exactly known geoid exchange parameters, this transformation will often by only approximately correct. Therefore BINGO can estimate this transformation optional simultaneously new.

Equation preview
(2.1.3/3)

This transformation has seven parameters: three shifts in vector XD, three small rotations Φ, Ω and Κ and in the transformation matrix T as well as the scale s. The user himself can choose the parameters to be used.
