9.6.2 Simulation of a facade photographed by a stereo metric camera

This example shows that a facade can be plotted by a calibrated stereo metric camera without further survey measurements. The base of the stereo metric camera and the additional stereo metric camera conditions give the scale and stabilise the block. The achieved standard deviations of the object point clearly show that for graphical plotting of a facade such a photo layout is fully satisfactory.

The relevant data are located in the directory \Bingo\DemoData\Simulation\.

Fig. 9.6.2-1 Photographing a facade with a stereometric camera
