ECCA Eccentricity vector from camera to GPS antenna and IMU calibration angles

Columns	format	contents/explanation
1-4	A4	ECCA
5-20	A16	Camera name
21-30 31-40 41-50	F10.0 F10.0 F10.0	ex' ey' ez'	Eccentricity vector e'
51-60 61-70 71-80	F10.0 F10.0 F10.0	dφ dω dκ	Calibration angles of the IMU (rotation between camera and IMU)

Fig. 5.3-1 Eccentricity vector

The eccentricity vector e' is defined in the image space. It points from the projection centre at the object side of the photo (Nodal point) towards the GPS-antenna. The values of vector components have to be indicated in the measuring unit of the object space.

For determining the vector components, the antenna is measured exactly in relation to the image plane of the camera. Then the distance from the image frame to the projection centre on the object side has to be added to the component e_z. This distance is not identical to the focal length of the camera. For the correct distance, please refer to the camera handbook. So the vector e´ is defined. The accuracy of its components is indicated in the ECES statement.

For several cameras the distance of the exterior projection centre to the sensor plane is indicated in the following chart. Standard-Front-filters have already been considered in these values. Further filters require additional corrections.

Camera	Focal Length	Objective	Distance	Comments
LMK	90	Superlamegon PI 5.6/90	161
	150	Lamegon PI 4.5/150 C	250
	150	Lamegon PI 4/150 D	240
	150	Lamegon PI 4/150 E	252
	210	Lamegoron PI 5.6/210 C	279
	300	Lamegor PI 5.6/300 C	272
RC20/RC30	88	8.8/SAGA-F	181
	153	15/4UAGA-F	282
	153	15/4UAGA-S	283	up to S/N 13269
	153	15/4UAGA-S	277	from S/N 13301
	213	21/4NAGA-F	271
	303	30/4NATA-F	270
	303	30/4NATA-F	314
RMK-A	153	Pleogon A2 4/153	240
	305	Topar A1 5.6/305	284
RMK-TOP	153	Pleogon A3 4/153	254
	305	Topar A3 5.6/305	262
Distances sensor plane – exterior projection centre
